| 产品型号 Type | 尺寸Dimensions/mm | 重量 Wt(g/set) | 参数Parameters | AL -value(1±25%)/(nH/N2) | AL -value(1±30%)/(nH/N2) | |||||||||||
| A | B | C | E | F | C1/mm-1 | Le/mm | Ae/mm2 | Ve/mm3 | 1kHz，0.25V，10Ts，25±3℃ | |||||||
| KH5 | KH7 | KH10 | KH12 | KH15 | ||||||||||||
| UU9.8-1 | UU9.8 | 9.8±0.3 | 7.2±0.2 | 2.7±0.2 | 4.1min | 4.3±0.2 | 1.58 | 4.45 | 34.4 | 7.7 | 267 | 1000 | 1400 | 2000 | 2500min | 2800min |
| UU10.5-1 | UU10.5 | 10.5±0.3 | 8.0±0.3 | 5.0±0.25 | 5.2min | 5.5±0.4 | 2.85 | 3.11 | 40.4 | 13.0 | 524 | 1400 | 1700 | 2500 | 3000min | 3500min |
| UU11-1 | UU11 | 11.0±0.3 | 9.3±0.2 | 6.0±0.3 | 6.0±0.3 | 6.9±0.2 | 3.90 | 3.20 | 47.3 | 14.8 | 699 | 1900 | 2700 | 3900 | 3300min | 4100min |
| UU16-1 | UU16 | 16.0±0.3 | 10.1±0.2 | 5.9±0.3 | 6.6min | 6.1±0.3 | 7.73 | 1.99 | 51.2 | 25.7 | 1317 | 1800 | 2500 | 3550 | 4000min | 4800min |
| UU18-1 | UU18 | 18.0±0.3 | 11.5±0.2 | 4.6±0.2 | 8.9±0.3 | 7.2±0.3 | 6.65 | 2.95 | 60.5 | 20.4 | 1235 | 2130 | 2900 | 4200 | 3500min | 4400min |
| UU26-1 | UU26 | 26.0±0.35 | 4.7±0.15 | 12.0±0.3 | 18.0±0.3 | 1.35±0.15 | 6.50 | 1.27 | 52.8 | 41.6 | 2192 | 5000 | 7000 | 9900 | 8500min | 10500min |
| UU26.4-1 | UU26.4 | 26.5±0.3 | 17.1±0.2 | 16.25±0.15 | 16.85±0.25 | 12.1±0.2 | 41.62 | 1.23 | 97.5 | 79.6 | 7759 | 5200 | 7200 | 10300 | 8700min | 10800min |
